During a power outage, keeping a full-size refrigerator running is the first question most households have. A portable power station can do it. But most people are sizing the station on the wrong number — and a few are losing the load entirely because of a setting nobody told them to change.

Here are the four places the math goes wrong, with the correct calculation for each.

This page uses the same assumptions as the Off-Grid Bench calculator: AC loads draw through an inverter at 85% efficiency (÷ 0.85); LFP batteries are used to 90% depth of discharge (÷ 0.90).

Issue 1: Checking the Wh, ignoring the peak watt rating

A refrigerator compressor demands a surge of power at startup — typically 3–6 times its running draw — lasting 1–3 seconds. If the station’s peak (surge) watt rating is lower than the fridge’s startup requirement, the inverter trips the moment the compressor tries to start. The station still has plenty of Wh. The fridge won’t run.

According to Portablevolt’s surge wattage guide (July 2026), full-size residential refrigerators run on 150–400 W once the compressor settles but surge to 600–1,800 W at startup. The Generator Size Calculator’s refrigerator entry puts the surge at 600–1,200 W for a 150 W running refrigerator specifically.

Fridge size	Running W (typical)	Startup surge (typical)	Station peak rating needed
Small (15–18 cu ft)	~100 W	500–700 W	≥ 700 W
Mid (19–22 cu ft)	~150 W	800–1,200 W	≥ 1,200 W
Large (23–26 cu ft)	~200 W	1,200–1,800 W	≥ 1,800 W

Surge figures are general estimates from the sources above; the spec sheet or data plate for your specific refrigerator is the authoritative number. Most 1,000 Wh and larger LFP stations carry a 2,000 W peak rating — enough for the middle row. A 500 Wh station with a 1,000 W peak may fail to start a mid-size fridge even if the Wh would otherwise cover several hours of runtime.

The same surge-first sizing logic applies to sump pumps, where the numbers are much higher: Sump Pump Backup Power.

Issue 2: Leaving eco mode on

Eco mode on a portable power station cuts the inverter when the load drops below a threshold — typically 50–100 W. The feature exists to prevent phantom drain when a phone charger sits connected but not actively charging. It breaks refrigerators.

Here is the sequence: the compressor runs, the fridge reaches temperature, the thermostat closes. The compressor drops to zero watts. Eco mode sees the load fall below threshold and shuts the inverter off entirely. Fifteen minutes later, the thermostat calls for cooling. The inverter is already off. The compressor cannot restart. The interior warms up, and no alarm sounds.

Reviewers running refrigerators from portable power stations report this failure mode consistently across brands. The fix is one step: disable eco mode before connecting the refrigerator. The efficiency cost is negligible compared to the failure risk.

Note: this applies to AC-outlet loads. USB and DC ports on most stations are not affected by the eco mode setting.

Issue 3: Calculating as if the compressor runs continuously

A residential refrigerator compressor cycles on and off. According to The Green Watt’s refrigerator wattage breakdown, the compressor runs roughly 30–40% of the time under normal household conditions (approximately 70 °F ambient, normal door use). This is a general estimate — a warmer room or frequent door openings will push the duty cycle higher.

Using 35% duty cycle as the working figure:

Fridge size	Running W	Avg W (35% duty)	12 h AC draw	From LFP station *	Station for 12 h	Station for 24 h
Small (15–18 cu ft)	100 W	35 W	420 Wh	549 Wh rated	700 Wh LFP	1,500 Wh LFP
Mid (19–22 cu ft)	150 W	53 W	630 Wh	824 Wh rated	1,000 Wh LFP †	2,000 Wh LFP
Large (23–26 cu ft)	200 W	70 W	840 Wh	1,098 Wh rated	1,500 Wh LFP	3,000 Wh LFP

* Formula: running W × duty cycle × hours = AC Wh → ÷ 0.85 (inverter) = station draw → ÷ 0.90 (LFP DoD) = rated capacity needed → round up to next standard size.

† 824 Wh is the rated capacity needed (the label Wh, after the 90% DoD step). The actual draw from the battery is 741 Wh; a 1,000 Wh LFP delivers 900 Wh usable — about 21% more than the fridge draws. If any other load shares the station, move to 1,500 Wh.

The common calculation error is multiplying running watts straight through: 150 W × 12 h = 1,800 Wh. That overstates the actual draw by more than 2× and makes the problem look impossible. The duty cycle is what makes the numbers workable.

Search for 2,000 Wh LFP stations on Amazon →

To add a CPAP, router, or lights to the same station during an outage, use the Off-Grid Bench calculator for the full mixed load.

Issue 4: The warm-restart drain

When a fridge has been off for any length of time — either because the outage started before you switched to station power, or because it sat warm while you located the station — the compressor runs at nearly 100% duty cycle until the interior cools back down. That typically takes 30–60 minutes.

For a 150 W compressor:

Phase	Duration	Duty cycle	AC draw	From station (÷ 0.85)
Warm restart	1 h	~90%	135 Wh	159 Wh
Normal cycling (after cool-down)	11 h	35%	578 Wh	680 Wh
Total (12 h, warm start)	—	—	713 Wh	839 Wh → 932 Wh rated

A fridge already at temperature draws 741 Wh from the battery (900 Wh usable in a 1,000 Wh LFP), leaving about 21% margin. A fridge coming in warm draws 839 Wh — still within the 900 Wh usable, but with only about 7% margin. The 1,500 Wh station removes that tightness on a warm start.

Frequently asked questions

Does it matter whether the station uses LFP or NMC chemistry?

Two ways it matters here. Depth of discharge: NMC stations are typically sized at 80% versus 90% for LFP. A 1,000 Wh NMC station yields ~800 Wh usable; 1,000 Wh LFP yields ~900 Wh. For the mid-size fridge at 12 hours (839 Wh drawn from the station), an 800 Wh NMC yield falls short. You would need at least 1,200 Wh NMC to match 1,000 Wh LFP. Cold weather also reduces NMC capacity more than LFP — relevant if the station sits in an unheated garage during a winter storm. Details: Power Station Capacity in Cold Weather.

Can I run a refrigerator and a chest freezer at the same time?

Add the two running wattages for the average draw calculation. For surge, use the larger surge figure plus the smaller running wattage (compressors rarely start simultaneously). A 150 W fridge and 150 W freezer together draw roughly 1,482 Wh from the station (about 1,650 Wh of rated capacity) over 12 hours — a 2,000 Wh LFP station with a 2,000 W+ peak rating covers both.

What about the ice maker?

Ice makers add roughly 200 Wh per day when actively cycling (a small heater plus a water valve). During an outage there is no need for new ice — turning the ice maker off removes that draw and the added load variation.
